Caractéristiques techniques
- Printing method
- Thermal
- Number of dots
- 864 / 2x400 or 536+296
- Resolution (dots/mm)
- 8
- Printing width (mm)
- 104 / 2x50 or 66+34
- Paper width (mm)
- 114 / 2x56 or 72+40
- Max. paper thickness (um)
- 80
- Paper loading
- Automatic
- Printing speed (mm/s)
- 90
- Paper detection
- Opto sensor
- Temperature detection
- Thermistor
- Head-up or Cover-open detection
- Switch
- Voltage range (Logic | Head)
- 5 ± 5% V | 18-26.5 V
- Dot resistance (Ohm)
- 1500 ± 10%
- Energy per dot (mJ)
- 0.29
- Stepper motor (Ohm)
- Bipolar (150)
- Weight (g)
- 260
- Life/reliability
- 50km/ 100M pulses
- Operating temperature (°C)
- 0 to +50
- Operating humidity (%)
- 20 to 85 non cond.
- Dimensions (WxDxH mm)
- 156x70x27
- Cutter
- Optional
