Caractéristiques techniques
- Printing method
- Thermal
- Number of dots
- 384
- Resolution (dots/mm)
- 8
- Printing width (mm)
- 48
- Paper width (mm)
- 58
- Max. paper thickness (um)
- 80
- Paper loading
- Easy Loading
- Printing speed (mm/s)
- 50
- Paper detection
- Opto sensor
- Temperature detection
- Thermistor
- Head-up or Cover-open detection
- Opto sensor
- Voltage range (Logic | Head)
- single 3-7.2 V
- Dot resistance (Ohm)
- 123 ± 3%
- Stepper motor (Ohm)
- Bipolar (12)
- Weight (g)
- 80120
- Life/reliability
- 100km/ 100M pulses
- Operating temperature (°C)
- -5 to +50
- Operating humidity (%)
- 20 to 85 non cond.
- Dimensions (WxDxH mm)
- 76.8x77.4x43.5
- Cutter
- Tear bar
- Paper roll diam. max. (mm)
- 32
- Expanded Flash memory
- No
- Expanded RAM memory
- No
- PCMCIA slots
- No
- Character set
- 3
- Character size
- 9 x 20, 13 x 24, 8 x 16
- Characters per line (max.)
- 48
- Interfaces
- RS232, TTL. Centronics
- Graphics
- 5 modes
- Barcodes
- UPCA-E, EAN 13-8, Code 39, ITF 2/5, Codabar, Code
- Windows drivers
- 95 / 98 / ME / XP / NT / 2000
- Zero power mode (sleep mode)
- Yes
- Auto wake-up on received data
- Yes
- Functional keyboard
- Yes
