Caractéristiques techniques
- Printing method
- Direct thermal line head
- Printing width (mm)
- 48
- Paper width (mm)
- 58
- Paper capacity
- 48mm diameter
- Printing speed (mm/s)
- MPP8200/MPP8220/MPP8250: 13 lines of text per second (max) / MPP8210: 2 lines of text per second (max)
- Power supply
- MPP820/MPP8210: 5-8 VDC / MPP8220/MPP8250: 10-35Vdc
- Dimensions (WxDxH mm)
- MPP8200 series/MPP8250 88mm x 88mm x 45.5mm / MPP8220 88mm x 88mm x 63.5mm / Panel cut-out 82 x 82mm
- Character set
- UK / United States (437)
- Character size
- 3mm x 2mm, 3mm x 1.5mm or 3mm x 1mm (Approx. 13, 17 or 25cpi)
- Characters per line (max.)
- 48, 32, 24(default), 16 and 12
- Character matrix
- 8x24, 12x24 or 16x24
- Horizontal dot pitch
- 0.125mm (Approx. 200dpi)
- Vertical dot pitch
- 0.125mm
- Text line composition
- 384x24 dots
- Interfaces
- Interface USB USB v2.0 / Serial / Data format RS232 (Default, 1 Start, 8 Data, 1 Stop, No Parity) / Baud rates 300, 600, 1200, 2400, 4800, 9600 & 19200, 38400, 5700 & 115200 / Handshaking Hardware (CTS line) or Software (XON/XOFF) / Parallel / Input Data
- Country codes
- USA, France, Germany, UK, Denmark I/II, Sweden, Italy, Japan, Norway, Spain I
- Current consumption
- MPP8200 4A peak / MPP8210 2A peak / MPP8220/MPP8250 2.7A @ 10V, 1.75A @ 15V,1.5A @ 20V, 1.2A @ 25V, 1.1A @30V, 1A @35V peak
